GRADE 5 STRENGTH + CORROSION RESISTANCE
Magni coated fasteners employ a three layer coating system that consists of an inorganic zinc-rich first coat and an aluminum-rich organic second coat. Friction modifiers are integrated into the topcoat, resulting in repeatable torque tension characteristics during assembly. Grade 5 bolts are stronger than A307 zinc, hot dip galvanized or 300 series stainless steel bolts. Magni coating provides superior corrosion resistance; withstanding 1500 hours of Salt Spray per ASTM B-117.
Disclaimer: This photo represents Grade 5 bolts tested in aluminum solar panel racking material. Results may vary.
Bridges
Water Management Systems
EV Charging
Guard Rails
Wind Power
TECHNICAL SPECIFICATIONS
Performance Data*
Coating Thickness
5 microns minimum (topcoat) over
8 microns minimum (basecoat)
Coefficient of Friction
Per NES D3002 ± .02
DURA-CON
DURA-CON-E
DURA-CON-J
DURA-CON-R
DURA-CON-T
0.13
0.10
0.28
0.16
0.20
Cyclic Corrosion Resistance
GCCT-A Toyota
CCT-I Nissan
CCT Honda
30 cycles
80 cycles
40 cycles
Performance Data*
Color
Gray, green, silver
Salt Spray
Per ASTM B117
1,500 hours
*Typical Values - official specifications available upon request
OEM Specifications
Alstom
ASTM
Fisher
Jaguar LandRover
Mercury Marine
Nissan
DTRF 150611revF1
F2833 Grade 2
FFS6B1-NCF1
STJLR.50.5043-A3
8M0057329
NES M4601
Click here to download a printable PDF version of the Magni 565 Product Data Sheet.
Stocked Products
Most fasteners can be coated in Magni corrosion resistant coating. For more information, or a quote on custom Magni coated fasteners, contact us.
