MKT Glazing Anchors

MKT Fastening offers glazing expansion anchors and other fasteners that are made in the USA. MKT concrete anchors for curtainwall applications come in carbon steel, zinc and stainless steel finishes, and many are approved for use in cracked concrete. MKT Fastening... a solid connection.

Need an MKT glazing anchor you don't see here? Call us at (800) 634-0406 or contact us and we'll help you get what you need.




SZ High Load Anchor

Steel Glazing Anchors

Available Materials

  • High strength steel
  • Flat head style available by special order

Features/Advantages

  • ACI 318 category 1 anchor for cracked or uncracked concrete.
  • Required hole diameter equals anchor diameter.
  • Equipment can be removed. The bolt and sleeve can be removed for a flush surface.
  • The expansion sleeve and cone remain in the hole.
  • Exceptional strength coupled with the ability to resist seismic loads.
  • Metric dimensions for international use.
  • Collapsible sleeve allows for secure clamping force.
  • Embedment depth is marked on each anchor for easy installation.
  • Multiple head styles available.

Sup-R-Stud® +

Stainless Steel Glazing Anchors

Available Materials

  • Carbon steel, zinc plated
  • Carbon steel, mechanically galvanized Class 65
  • Grade 5, yellow di-chromated
  • 303/304 stainless steel
  • 316 stainless steel

Features/Advantages

  • Required hole diameter equals anchor diameter
  • Excellent for setting immediately
  • Can be loaded immediately
  • Can be set in a bottomless hole
  • Simple installation
  • Nut and washer supplied in package
  • ROHS compliant (except for Grade 5)


Sup-R-Stud® TZ

Steel Glazing Anchors

Features/Advantages

  • Steel zinc plated
  • ACI 318 category 1 anchor for cracked or uncracked concrete
  • Suitable for resisting seismic design loads
  • Required hole diameter equals anchor diameter
  • Can be loaded immediately
  • Nut and washer included with anchor
  • Simple to install
  • For medium to heavy loads

Sup-R-Sleeve®

Stainless Steel Glazing Anchors

Available Materials

  • Carbon steel, zinc plated
  • 304 stainless steel on select sizes

Features/Advantages

  • Length of sleeve makes anchor more forgiving than a wedge anchor and induces less stress on the substrate
  • Can be used in solid or hollow masonry
  • Works in a bottomless hole
  • Required hole diameter equals anchor diameter
  • Supplied assembled with 4 possible head styles


Sup-R-Drop®

Stainless Steel Glazing Anchors

Available Materials

  • Carbon steel, zinc plated
  • 304 stainless steel
  • 316 stainless steel

Features/Advantages

  • Ideal for flush-mounting applications
  • Pre-assembled for ease of installation
  • Female threads accept standard UNC bolts or threaded rods (1/4" to 3/4")
  • Slotted body is precision-matched to tapered internal plug foruniformexpansion
  • Knurled body increases friction connection between anchor and wall of hole

Taper Bolt®

Steel Glazing Anchors

Available Materials

  • Grade 5, zinc plated
  • Other metals and finishes are available by special quote
  • Eye bolt version available by special quote

Features/Advantages

  • Required hole diameter equals anchor diameter
  • Variation in hole size can be accommodated by turning the expander nut
  • Equipment may be removed and replaced. The bolt is simply re-inserted and torqued to obtain original holding power (the nut stays in the hole)
  • Bolt can be removed and re-used with a new nut after cleaning and lubricating the threads
  • Strength – the highest shear strength of any expansion anchor
  • Withstands vibratory loads
  • Works in a bottomless hole




MKT Glazing Fasteners Code Approvals

ProductICC-ESLARRMiami-Dade
Liquid Roc 700+
MKT VME Epoxy
SRS TZ
Sup-R-Stud+
SZ High Load
